EUROCARD FULL LINE PATTERN – 100x80mm – FR4 (1pc/bl.)

EUROCARD FULL LINE PATTERN – 100x80mm – FR4 (1pc/bl.)

6,95

Out of stock

EUROCARD FULL LINE PATTERN – 100x80mm – FR4 (1pc/bl.)

Out of stock


SKU: ECL1/2 Check our full Whadda product transition list Category:
Free shipping
Free shipping from €50
EU shipping
EU shipping in 1 to 5 days
Belgian shop
Belgian shop
Return policy
14-day unmodified return policy

Description

Features

  • High-quality materials: This Eurocard is made of high-quality epoxy resin that is also flame-retardant FR-4. The high-quality contacts ensure excellent conductivity.
  • Modular design: Eurocards are designed to fit into modular electronic systems. They can be slid into a chassis and connected to other circuit boards and components via connectors.
  • Perfect conductivity: This Eurocard features high-quality copper conductors and traces for optimal conductivity.
  • Compatible with DIN connectors: This Eurocard is compatible with DIN41612 and DIN41617 type connectors or other similar industrial connector types that conform to Eurocard specifications.
  • Broad application range: Eurocards are often used in industrial, electronic, and other technical applications that require modular, standardized printed circuit boards. Additionally, they can accommodate a variety of electronic components such as ICs, resistors, capacitors, connectors, and more, depending on the specific application., depending on the specific application.

Specifications

  • Product basic info:
    • Primary colours: Green
    • Additional colours: Red
    • Additional detailed colours: Metallic copper red
    • Depth unit: 100 mm
    • Height unit: 2 mm
    • Width unit: 80 mm
    • Weight unit: 23 g
    • Material: Epoxy
    • Additional material: Copper
  • Physical properties:
    • Number of pieces: 1
  • Technical data:
    • Board type: Single sided
    • Bore diameter: 1 mm
    • Track type: Full line
    • Weight coating: 0.03 g/cm²
  • Compatibility:
    • Compatible eurodin connectors: DIN 41612, DIN 41617

Additional information

Weight34,5 g
Dimensions0,20 × 12,00 × 17,00 cm
