MULTIFUNCTIONAL SMD REPAIR STATION

Description

This product is a replacement of: VTSS100

Features

• Perfect functionality: This soldering station has loads of functions: an automatic standby function, adjustable air supply and temperature for different applications and an automatic cooling system with automatic shutdown. You can also use the soldering station as a hot air gun — to shrink heat-shrink tubing — and it is compatible with numerous nozzles. Moreover, this soldering station heats up quickly so you can get started quickly.
• Brushless motor: The brushless motor guarantees gentle airflow, long life and quiet operation.
• Memory function: The last used temperature setting is stored in memory after switching off so you don’t have to set it again for the next use.
• Suitable for professionals or DIYers: This soldering station with hot-air technology is perfect for both professionals and DIYers. The hot-air process allows easy and gentle soldering or removal of SMD parts.
• Wide range of applications: The soldering station is suitable for soldering and desoldering a wide range of parts such as SOIC, CHIP, QFP, PLCC, BGA or telephone wires, shrinking/drying/degumming, thawing, preheating of parts, making it versatile.

Specifications

• Product basic info:
  • Instruction manual languages: Dutch, English, French, German, Italian, Polish, Portuguese, Spanish
  • Primary colours: Grey
  • Additional colours: Black
  • Depth unit: 212 mm
  • Height unit: 172 mm
  • Width unit: 122 mm
  • Weight unit: 1140 g
  • Material: ABS
• Physical properties:
  • Display type: Digital
  • Number of channels: 3
• Electrical data:
  • Fuse type: F 5 A (fast) blow
• Technical data:
  • Power rating: 300 W
  • Air flow rate range: 3-24 l/min
  • ESD safe: No
  • Fast heating: Yes
  • Auto standby function: Yes
  • Automatic cooling system: Yes
  • Automatic power-off function: Yes
  • Brushless motor fan: Yes
  • Adjustable airflow: Yes
  • Maximum noise level: 50 dB
• Set-up options:
  • Memory function: Yes
  • Temperature range desoldering: 100-500 °C
  • Temperature readout: Celcius (°C) – Fahrenheit (°F)
• Power supply:
  • Input frequency rating: 50 Hz
  • Input voltage rating VAC range: 220-240 V
